Introduction

I’ve been wanting to take a look at Citrix XenClient type 1 hypervisor for some time, but my trusty HP Elitebook 8530W, despite having the correct Intel v-pro chipset, contained an NVidia graphics GPU so was unsuitable.

I’d been wanting a smaller, lighter laptop for a while for use when travelling (the HP Elitebook weights alot, even with SSD hard disc) so checked the XenClient HCL and narrowed down my choices to either Lenovo X1 or X220. In the end, the Lenovo X220 won out, and I grabbed a bargain in the “Black Friday” sales.

This is the first part of a series on posts on XenClient:

Part 1 – installation and management GUI (this post)

Part 2 – Creating and configuring a Windows 7 VM

Part 3 – Image management using Synchroniser

Part 4 – Findings

Click on any of the screenshot thumbnails for the full size versions.

Installation

This was remarkably simple. Downloaded the ISO (mycitrix account required), then because the Lenovo X220 doesn’t have a CD/DVD drive, I created a bootable USB pen drive using this utility from PenDriveLinux.

Booting from the into the XenClient installer, then followed the wizard to install the software. I chose to destroy the existing factory Lenovo Windows 7 partitions. Ideally, I’d have opted for creating a multi-boot configuration, but the rather small 128Gb SSD hard disc would of become a limiting factor, so I may just swap the hard drive over if I need an alternate OS/Hypervisor.

Tour of the XenClient Receiver

Citrix call the XenClient administrator interface “Receiver for XenClient”.

Ribbon

The XenClient Receiver GUI follows the now-familiar Citrix grey look and feel, with short-cuts across the top to the various configuration options.

There is battery status indicator in the far right corner, and network icon along side it to configure both wired and WiFi networks, and the System configuration button.

On the left are Power Control drop-down, and Add VM shortcut.

Clicking on Network you get a list of the available wireless networks:

As you can see my neighbourhood is “well connected” when it comes to WiFi!

You can choose “Edit connections..” from this menu to edit/remove any existing connections you have setup:

System options

Clicking on the System options we get the main configuration settings window appear.

1. Wallpaper settings

2. Power options

Here we can configure the lid closure actions, and screen brightness.

3. Interface

The user interface options such as mouse/trackpad speeds and GUI language.

4. Login

Note the message about synchroniser credentials. Unfortunately I didn’t grab a screenshot of this before I attached my system to a Sychroniser, so there may of been some additional options here.

5. Synchroniser

This is where you “pair” the XenClient with the remote Synchroniser. Once paired, the connection status, version of the server, and userid in use are reported as shown in the screen shot.

6. Software

The version of XenClient is shown here, with an option to update. It’s interesting that the update URL is not set, even when you’ve configured a Synchroniser.

7. Hardware

Hardware details include memory usage, PCU and GPU types.

8. Networking

The various MAC addresses and chipsets of the detected networking hardware.

9. Status report

For troubleshooting, XenClient can build a status report, including screenshots of the VMs. This is wizard-based:

The file is saved to /storage/status-report/ on Dom0 so can be retrieved using SCP/SFTP.

There is also a mini web server that you can temporarily bring online to server this file via Dom0 to an external PC via port 5000:

What does this file contain? Quite a bit! Here’s the complete listing:

acpi-info.tar.bz2 ac_adapter-state.log bed.out.tar.bz2 blktap2-devices.log brctl_show.log config-data.tar.bz2 cpuinfo.log ctxusb-daemon-state.log db.tar.bz2 df-h.log dirlisting.txt disksyncmgr.out.tar.bz2 dmesg-sysrq.log dmesg.log dmidecode.log edid-igfx.log edid-parsed.log eth0-link-state.log eth0-oper-state.log ethtool.log fdisk-l.log fstab.tar.bz2 guest-process-stats.log host-installer.log.log hvm-info.log ifconfig-a.log ifconfig.log install-data.tar.bz2 iwlist-scan.log large-files.log ls-backend-certs.log ls-sys-block.log lsmod.log lspci-mmnn.log lspci-mmnnv.log lspci-vvv.log lspci-xxx.log lsusb-t.log lsusb-v.log lsusb.log lvs.log mount-l.log netstat-ln.log netstat-tn.log ping-uivm.log ps-axfl.log psauxZ.log pvs.log rfkill.log route-n.log screenshots.tar.bz2 selinux-config.log sound-alsactl-store.log sound-amixer.log status-report.log storage-disks-scan.log swaps.log syslog.tar.bz2 temperature.log top.log tpm_version.log txt-stat.log uname-a.log upgrade-data.tar.bz2 USB_fakenames.conf.log usb_pm_info.log user-report.xml.log vgmch_dump_regs.log vhd-check.log vhdsync-cksums.tar.bz2 vm-customizations.tar.bz2 vms.tar.bz2 wlan0-link-state.log wlan0-oper-state.log xc-diag.tar.bz2 xenclient.conf.log xenmgr-xenvm.tar.bz2 xenops_list.log xenops_physinfo.log xenstore-ls.log xenstored-access.tar.bz2 xentop.log xen_dmesg.log Xorg.0.log.tar.bz2 84 File(s) 1,389,543 bytes 2 Dir(s) 16,000,061,440 bytes free Keyboard shortcuts

There are a number of useful CTRL/ALT key combinations whilst inside the Receiver console:

CTRL+Q : Reload the console

CTRL+SHIFT+T : Open a SSH terminal window

CTRL+SHIFT+H : Open a larger terminal window

CTRL+SHIFT+I : Easter Egg! (ASCII Invaders – nice!)

CTRL+ALT+r : Create a status report

CTRL+ALT+Backspace : Lock the Receiver screen

ALT+0 : Return to the Receiver (from within VM)

ALT+n : Switch to VM number n



So that completes the installation and tour of the XenClient Receiver.

In part two, I’ll create a Windows 7 x 64 Virtual machine, and take a look round the options we have of exposing the underlying hardware (OEM indentification strings in the BIOS and 3D graphics chipset) to the VM, and what VM management features we have via Receiver GUI.

Thanks for reading. Check back soon!

Useful resources

PenDrive Linux - for creating the bootable USB installation

Kees Baggerman blog post – some useful tips on getting up and running

XenClient documentation (PDF) – sadly not on eDocs!
